Model No.:Sp100285
Brand:CUMMINS
Warranty:3 Month
Certification:ISO
Condition:New
Rated Load:3-6t
Transmission:Hydraulic - Mechanical
Load and Unload Mode:Front Discharge
Walking Mode:Wheeled
Type:Medium-sized Loader
Packaging:box
Productivity:10000
Transportation:Ocean,Land,Air
Place of Origin:CHINA
Supply Ability:1000 Pc per day
Certificate:ISO
Port:Shanghai,Qingdao,Guangzhou
Payment Type:L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm:FOB,CFR,CIF,EXW,FCA,CPT,CIP
4WG180 4WG200 TRANSMISSION SPARE PARTS
GEARBOX HOUSING ASSEMBLY 4644 101 -12 0730108158 SHIM S=1.6 0730 108 158
1 4644301391 GEARBOX HOUSING 4644 301 391 -13 0730108159 SHIM S=1.8 0730 108 159
2 0336302027 PLUG (M30*1.5)0336 302 027 -14 0730108160 SHIM S=2.0 0730 108 160
3 0634304275 O-RING (27*2)0634 304 275 -15 0730108161 SHIM S=2.2 0730 108 161
4 0899317344 TYPE PLATE 0899 317 344 -16 0730108162 SHIM S=2.4 0730 108 162
5 0631311009 RIVET 0631 311 009 -17 0730108163 SHIM S=2.6 0730 108 163
6 0636305046 PLUG (AM14*1.5)0636 305 046 -18 0730108164 SHIM S=2.8 0730 108 164
7 0634306522 O-RING 0634 306 522 -19 0730150759 THRUST WASHER 0730 150 759
8 4644301298 COVER PLATE 4644 301 298 -20 4644303529 THRUST WASHER 4644 303 529
9 4644301192 COVER PLATE 4644 301 192 -21 4644308625 GEAR (Z=63)4644 308 625
10 0636015278 SCREW (M8*16)0636 015 278 -22 4644308265 THRUST WASHER 4644 308 265
11 0630001012 WASHER 0630 001 012 -23 0730150773 THRUST WASHER 0730 150 773
12 4466351081 SEALED CAP 4466 351 081 -24 0750119100 ROLL.BEARING ASSEMBLY 0750 119 100
13 0634306525 O-RING 0634 306 525 -25 4644308266 WASHER 4644 308 266
14 0636305026 PLUG (CM38*1.5)0636 305 026 -26 4644308071 WASHER 4644 308 071
15 0636305019 PLUG (AM26*1.5)0636 305 019 -27 4644351070 PISTON 4644 351 070
16 0634303233 O-RING 0634 303 233 -28 0750112139 PACKING RING 0750 112 139
17 0750131027 PERMEABILITY PARTS 0750 131 027 -29 4644351094 THRUST WASHER 4644 351 094
18 4644301279 CLAPBOARD 4644 301 279 -30 4642308555 THRUST WASHER 4642 308 555
19 0636804003 BOLT 0636 804 003 -31 0750112140 PACKING RING 0750 112 140
20 4644301088 SEALED CAP 4644 301 088 -32 0732041183 PRESSURE SPRING 0732 041 183
LAYSHAFT 4644 108 -33 4642308083 GUIDE RING 4642 308 083
1 4644308611 SHAFT 4644 308 611 -34 550630531346 V-CUP 550630531346
2 0634313529 O-RING 0634 313 529 -35 4642308084 GUIDE RING 4642 308 084
3 4644308610 THRUST WASHER 4644 308 610 -36 0635303203 NEEDLE BEARING 0635 303 203
4 4644308614 IDLEER GEAR SHAFT Z=36(HVZ)4644 308 614-37 0730513610 RETAINING RING 0730 513 610
5 0636104146 CAP SCREW 0636 104 146 -38 0635303205 NEEDLE BEARING 0635 303 205
6 0750119101 ROLL.BEARING ASSEMBLY 0750 119 101 -39 0730513611 RETAINING RING 0730 513 611
7 0630362024 PACKING WASHER (25)0630 362 024 -40 0730513181 RETAINING RING 0730 513 181
COUPLNG KV+K1 4644 151 -41 0730513434 SNAP RING 0730 513 434
1 4644351076 SHAFT 4644 351 076 -42 0730513436 SNAP RING 0730 513 436
2 0634313536 O-RING (49*3)0634 313 536 -43 0730513459 SNAP RING 0730 513 459
3 0734401106 PISTON RING 0734 401 106 -44 0730513457 SNAP RING 0730 513 457
4 0636610014 DOUBLE-SCREW BOLT 0636 610 014 -45 0730150779 THRUST WASHER 0730 150 779
5 0637006018 NUT 0637 006 018 -46 4644252097 SPUR GEAR 4644 252 097
6 0730003501 WASHER 0730 003 501 -47 0750115211 BALL BEARING 0750 115 211
7 0730003502 SHIM S=0.6 0730 003 502 -48 0501308830 CERATOCRICOID MUSCLE 0501 308 830
8 0730003503 SHIM S=0.8 0730 003 503 -49 4644252098 DISC CARRIER 4644 252 098
9 0730003504 SHIM S=1.0 0730 003 504 -50 0501309330 OUTER CLUTCH DISC 0501 309 330
10 0730003505 SHIM S=1.2 0730 003 505 -51 4644308329 INTERNAL FRICTION BLOCK 4644 308 329
11 0730108157 SHIM S=1.4 0730 108 157 -52 4644308330 INTERNAL FRICTION BLOCK 4644 308 330
